Productos / Hoppers for sandblasting and shot blasting / CB-2000
Hoppers for sandblasting and shot blasting
CB-2000

CORR BLAST hoppers allow working with steel shot, sand (not recommended due to its unhealthy conditions) and any other type of abrasive, without the need to make changes to the equipment or circuit accessories.

CORR BLAST hoppers are manufactured under ASME code (Boller & Pressure Vessel Code) and are enabled with prototype and design approval by LAW 11,459.

They are delivered with approval certificate and hydraulic test.


Download data sheet
Descripcion

Characteristics:

Tank: manufactured under ASME code with approval of Law 11.459.

Capacity: 2000 lts. 8 Tns. of steel shot or 3.2 Tns. of sand.

Outputs: 4 independent and simultaneous nozzles for 4 nozzles.

Control: Remote, dead man system. Electric or pneumatic.

Total height: 2900 mm.

Occupied diameter: 1700 mm.

Total unloaded weight: 1500 Kgs.

Movement: allows horizontal transport with legs provided for this purpose.
