Air line equipment
Buffer tank for compressed air ECO 500

They are used in fixed or on-site sandblasting and blasting installations and allow:

- An effective separation between the compressor and the projection equipment, avoiding dust recoil;

- Combined with a coalescing filter, they remove oil and water;

- Provides the necessary connections to power the different equipment of the installation.

Download data sheet
Descripcion

* Vertical mounting on 3 legs.

* Load hitch for on-site displacement.

* 1 "inlet connections.

* 1 "or 3/4" outlet connections depending on the model.

* Purge outlet, for safety valve and pressure gauge.

* Maximum working pressure: 1 Okg / m2

* Normal working pressure: 7kg / m2

Approval: delivered with hydraulic test and manufacturing and construction certificate according to ASME VIII Div. 1.

MODEL: CB-PL-ECO-500

CAPACITY: 500 LT

HEIGHT: 2100 MM

DIAMETER: 1920 MM
